QUICK Specifications |
|
| Angle Measurement | |
| Min. Resolution/Accuracy | |
| ES-101 | 0.5”/1” |
| ES-102 | 1”/2” |
| ES-103 | 1”/3” |
| ES-105 | 1”/5” |
| ES-107 | 1”/7” |
| IACS (Independent Angle Calibration System) | Standard om 1” & 2” models |
| Compensation | Dual-axis compensator |
| Distance Measurement | |
| Prism EDM Range | 4000m (ES-107 3000m) |
| Prism EDM Accuracy | 2mm+2ppm |
| Non-Prism Range | 500m |
| Non-Prism Accuracy | 3mm+2ppm (0.3-200m) |
| Measuring Time | Fine: 0.9 sec Rapid: 0.7 sec Tracking: 0.3 sec |
| Communications | |
| LongLink™ rover communications utilizing Class 1 Bluetooth | |
| USB 2.0 Slot | |
| RS-232C Serial | |
| General | |
| Display/Keyboard | Dual, Graphic, Backlit LCD (ES-107 Single) |
| Battery Operation | up to 36 hours |
| Dust/Water Protection | IP66 |
| Wireless Connection | Bluetooth Class 1 |
| Operating Range |
-20C to +50C |
